Thermal Imaging Riflescope TUBE
Fortune always favors those blessed by the monks. Read More
Features:
The Thermal Imaging Riflescope TUBE series features a 12um 640×512 high-capacity sensor and 2560×2560 resolution AMOLED display for superior image clarity. It boasts a 2600m detection range with a powerful 50mm optic and smooth magnification for precise targeting. With Bluetooth connectivity to LRF, it displays real-time distance measurements on-screen to enhance shot accuracy. The Ultra-Clear Mode ensures visibility in adverse conditions like fog and rain, while precise zeroing (1.2cm at 100m for TH50V2) allows for accurate shots. Additionally, it includes an upgraded microphone for recording voiceovers during video captures.
Technical Specs:
TH35V2
|
Model |
TH35 V2 |
|
Detector Specifications |
|
|
Type |
Uncooled Vox |
|
Resolution, pixels |
640 × 512 |
|
Pixel Size, μm |
12 |
|
NETD, mk |
≤ 25 |
|
Frame Rate, Hz |
50 |
|
Optical Specifications |
|
|
Objective Lens, mm |
35 |
|
Field of View (H×V), º |
12.5 × 10.0 |
|
Linear Field of View (H×V), m at 100m |
21.9×17.5 |
|
Optical Magnification, × |
2.5 ~ 10.0 |
|
Digital Zoom, × |
1 ~ 4 |
|
Eye Relief, mm |
50 |
|
Exit pupil Diameter, mm |
6 |
|
Diopter, D |
-5 ~ +3.5 |
|
Detection Range, m |
1800 |
|
(Target Size: 1.7m×0.5m, P(n)=99%) |
|
|
Display Specifications |
|
|
Type |
AMOLED |
|
Resolution |
2560 × 2560 (1.03”) |
|
Battery Power Supply |
|
|
Battery |
Built-in battery / 6600mAh + |
|
Max. Operating Time (22ºC), h* |
8.5 |
|
External Power Supply |
5V (Type C) |
|
Functions |
|
|
Wi-Fi / APP |
Support (InfiRay outdoor) |
|
Photo / Video Recorder |
Support |
|
MIC |
Support |
|
Bluetooth |
Support |
|
Operational Characteristics |
|
|
Memory Capacity，GB |
32 |
|
IP rating |
IP67 |
|
Operating Temperature, °C |
-20 ~ +50 |
|
Max. recoil power on rifled weapon (Eo), Joules |
6000 |
|
Compatible mounts |
Standard 30 mm rings |
|
Weight (without the 18500 battery), g |
< 915 |
|
Dimension, mm |
360 × 85 × 75 |
TH50V2
|
Model |
TH50 V2 |
|
Detector Specifications |
|
|
Type |
Uncooled Vox |
|
Resolution, pixels |
640 × 512 |
|
Pixel Size, μm |
12 |
|
NETD, mk |
≤ 25 |
|
Frame Rate, Hz |
50 |
|
Objective Lens, mm |
50 |
|
Field of View (H×V), º |
8.8 × 7.0 |
|
Linear Field of View (H×V), m at 100m |
15.4×12.3 |
|
Optical Magnification, × |
3.5 |
|
Digital Zoom, × |
1 ~ 4 |
|
Eye Relief, mm |
50 |
|
Exit pupil Diameter, mm |
6 |
|
Diopter, D |
-5 ~ +3.5 |
|
Detection Range, m |
2600 |
|
(Target Size: 1.7m×0.5m, P(n)=99%) |
|
|
Display Specifications |
|
|
Type |
AMOLED |
|
Resolution |
2560 × 2560 (1.03”) |
|
Battery Power Supply |
|
|
Battery |
Built-in battery / 6600mAh + |
|
Max. Operating Time (22ºC), h* |
8.5 |
|
External Power Supply |
5V (Type C) |
|
Functions |
|
|
Wi-Fi / APP |
Support (InfiRay outdoor) |
|
Photo / Video Recorder |
Support |
|
MIC |
Support |
|
Bluetooth |
Support |
|
Operational Characteristics |
|
|
Memory Capacity，GB |
32 |
|
IP rating |
IP67 |
|
Operating Temperature, °C |
-20 ~ +50 |
|
Max. recoil power on rifled weapon (Eo), Joules |
6000 |
|
Compatible mounts |
Standard 30 mm rings |
|
Weight (without the 18500 battery), g |
< 950 |
|
Dimension, mm |
365 × 85 × 75 |
